2013 - Logic Gates
Last Update: 26.06.2025
Maturity  | |
|---|---|
 Basic |  |
 Scope |  |
 Flow | |
 Cycle | |
Center  AND-Gate |
Periphery  OR-Gate |
Logic gates are fundamental building blocks of digital circuits. An AND-gate outputs a high signal only when all inputs are high, while an OR-gate outputs a high signal when at least one input is high.
WARNING: This entry is marked as experimental/in development.
